Injection Molding Practical Guide: 30 Common Problems & Solutions

Author:SWITEK
|
Release Date:2026.08.25
|
Views:645


Injection Molding Practical Guide: 30 Common Problems & Solutions

Covering machine tuning parameters, defect troubleshooting, equipment calculations & process control

Q 01   Why does the product produce flash at startup, then underfill after running for a while? What is the solution?

Cause & Countermeasure: At startup, the melt in the injection molding machine barrel has been heated for a long time, with low viscosity and good flowability, making it prone to flash; after running for a while, the melt continuously carries heat away, resulting in insufficient melt temperature, high viscosity, and poor flowability, leading to underfill. Solution: Gradually increase the barrel temperature after production has been running for a while.

Q 02   During production, the product underfills, and sometimes increasing injection pressure and speed has no effect. Why?

Cause & Countermeasure: After running for a while, the melt continuously carries heat away, causing the melt temperature to drop, viscosity to rise, and flowability to become extremely poor. At this point, pressure and speed alone cannot fill the cavity. Solution: Increase the barrel temperature.

Q 03   What are the causes and solutions for a product deforming into an oval shape?

Cause & Countermeasure: Uneven gating causes uneven pressure around the product, leading to oval deformation. Solution: Use three-point gating to ensure uniform injection and pressure distribution.

Q 04   What are the basic requirements for molds used in precision products?
Answer: The mold material must have good rigidity, low elastic deformation, and a low coefficient of thermal expansion.
Q 05   What is the purpose of conducting acid resistance tests on products?
Answer: To detect the magnitude of internal stress in the product and the locations of internal stress concentration, so that subsequent process adjustments can eliminate the internal stress.
Q 06   What are the causes and solutions for cracking at metal insert locations in products?

Cause & Countermeasure: During injection, the high-temperature melt encounters the cold metal insert and cools rapidly, generating extreme concentrated internal stress that leads to cracking. Solution: Preheat the metal inserts before production.

Q 07   What are the basis for selecting mold venting points and how should they be set reasonably?
Answer: Unreasonable venting points can cause product deformation or dimensional abnormalities. Vent slots should be opened at the last-filled areas where the melt completes filling and at locations prone to gas trapping and burning.
Q 08   What are the causes and solutions for products being prone to brittle cracking?

Cause & Countermeasure: Excessively high proportion of sprue regrind, or raw material remaining in the barrel and being heated for too long, leading to thermal degradation and aging. Solution: Increase the proportion of virgin material; regrind should generally be recycled no more than 3 times, and avoid prolonged residence of melt in the barrel.

Q 09   What are the causes and solutions for "fiber show-through" on the surface of glass-fiber-reinforced products?

Cause & Countermeasure: Melt temperature or mold temperature is too low, and injection pressure is insufficient, causing the glass fibers to not be fully encapsulated by the plastic and become exposed. Solution: Increase the melt temperature and mold temperature, and raise the injection pressure.

Q 10   What effect does the feed throat (hopper inlet) temperature have on the product?
Answer: Feed throat temperature that is too high or too low will cause uneven screw feeding and feed volume, leading to unstable plasticization, which in turn affects the product's dimensional accuracy and appearance.
Q 11   What are the causes and solutions for "white spots" inside transparent products?

Cause & Countermeasure: Cold slugs entering the cavity, or dust and impurities mixed into the raw material. Solution: Appropriately increase the nozzle temperature, add a cold slug well, and strengthen dust protection for the raw material.

Q 12 - 18 Core Injection Molding Machine Parameter Calculation Formulas & Concept Analysis

12. Injection Capacity (PW): PW = Injection Pressure (kg/cm²) × Injection Volume (cm³) / 1000

13. Injection Horsepower (PW): PW (KW) = Injection Pressure (kg/cm²) × Injection Rate (cm³/sec) × 9.8 × 100%

14. Injection Rate (V): V (cc/sec) = (π/4) × d² × r (d: barrel diameter, r: melt density)

15. Injection Thrust (F): F (kgf) = (π/4) × (D1² - D2²) × P × 2 (D1: cylinder inner diameter, D2: piston rod outer diameter, P: system pressure)

16. Injection Pressure (P): P (kg/cm²) = [(π/4) × (D1² - D2²) × P × 2] / [(π/4) × d²]

17. Plasticization Capacity (W): W (g/sec) = 2.5 × (d/2.54)² × (h/2.54) × N × S × 1000 / 3600 (h: screw front channel depth, S: raw material density)

18. Difference Between System Pressure and Injection Pressure: System pressure is the maximum working pressure set in the hydraulic circuit; injection pressure refers to the actual pressure applied to the melt during injection molding. The two are not the same.

Q 19    What are the basic selection requirements for injection molding machine hydraulic oil?
(1) Appropriate viscosity and good viscosity-temperature properties;
(2) Good lubricity and rust resistance;
(3) Good chemical stability, not easily oxidized or gelled at high temperatures;
(4) Good foam resistance;
(5) Minimal corrosiveness to machine parts and seals;
(6) High flash point (ignition point) and low pour point.
Q 20   What is the effect of hydraulic oil viscosity selection on injection molding machine operation?
When ambient temperature is high or system working pressure is high (difficult sealing and leak prevention), oil with higher viscosity should be selected; conversely, use lower viscosity oil. When operating speed is high (high flow velocity, high losses), oil with lower viscosity is appropriate; when operating speed is low, higher viscosity oil should be selected.
Q 21 - 23 Suck-Back and Melt Position Setting Tips

21. Correct Suck-Back Position Calculation: Suck-back position = check ring travel distance + screw override distance

22. Importance of Suck-Back Position Setting: If set too large, it easily draws in air, causing melt oxidation or bubbles; if set too small, it leads to high residual pressure in the barrel and excessive shear force, causing decomposition or nozzle drool. Control error is recommended not to exceed 0.4mm.

23. Melt Position Calculation: Melt position = product weight / (maximum stroke / maximum melt volume)

Q 24   What are the main advantages of gas-assisted injection molding (GAIM)?
It can evacuate the core of thick-walled parts to create hollow structures, saving material and shortening cycle time; uses gas to achieve uniform internal holding pressure, compensating for volumetric shrinkage; significantly reduces product internal stress, eliminating warpage and sink mark deformation.
Q 25   What are the causes and solutions for a piston rod outer diameter showing "narrow in the middle, wide at both ends"?

Cause & Countermeasure: The core pin overheats, causing uneven cooling shrinkage of the product. Solution: Make the core pin from phosphor bronze, which dissipates heat quickly, and add venting in the middle of the mold.

Q 26   What are the causes and solutions for cracking on spherical products after screen printing?

Cause & Countermeasure: Residual internal stress on the product surface, which cracks when attacked by screen printing solvents. Solution: Increase mold temperature to reduce stress, or eliminate internal stress through annealing treatment.

Q 27   What are the causes and solutions for easy breakage at the gate edge of eyeglass frames?

Cause & Countermeasure: Excessively high injection and holding pressure, leaving extreme residual stress at the gate. Solution: Reduce injection and holding pressure, and increase mold temperature.

Q 28   What are the causes and solutions for the four screw bosses on electrical enclosures easily cracking when screws are driven in?

Cause & Countermeasure: Weld lines (knit lines) exist at the screw bosses, causing insufficient strength. Solution: Increase venting at the mold boss locations, raise mold temperature, and accelerate injection speed to improve weld line strength.

Q 29    What is the root cause of injection molded product deformation?
Answer: It is mainly caused by uneven thermal shrinkage during cooling, or by the release of residual internal stress within the product triggering deformation.
Q 30   What are the causes and solutions for bubbles appearing in transparent PC enclosures?

Cause & Countermeasure: Insufficient raw material drying (moisture content), uneven wall thickness (vacuum bubbles), poor mold venting, or raw material decomposition. Solution: Fully dry the raw material, increase mold venting, and optimize the wall thickness structure.
